As we live in the age of information, laptops are found in almost every household. Given the rapid pace of new development in computers, mold makers are exploring every possibility to shorten cycle times. As the rising international oil price drives up the costs of polymers, mold tryouts become costly to businesses. The need for an alternative to this trial and error method is essential for reducing development cost and time. Therefore, Moldex3D, the computer-assisted engineering software, is growing in popularity with mold and part designers. The case study presented here demonstrates how simulation analysis can minimize the difference between partial and overall wall thickness and further improve dimensional difference and warpage problems.
As the advancement of technology, laptop designs are becoming thinner and lighter by reducing the body thickness to meet easy portability needs. In some cases when we need to consider other product factors, wall thickness can increase in some areas while decreasing overall, and this is how wall thickness difference occurs. The difference often causes dimensional difference and warpage problems.
In the early days, time and money spent on mold trials kept rising since the molding machine operators had to ensure product quality and meet customer demand through the process of fine-tuning parameters. Design changes are required if the problem cannot be solved by performing machine adjustments. However, this may result in additional mold trial costs and even delay time-to-market. Dimensional difference and warpage have been the serious real-world molding problems. With help from Moldex3D, the leading computer assisted engineering software, mold makers can easily investigate potential defects and fix them in advance.
Using Moldex3D software, SMPI performed the part thickness variations analysis for the top cabinet of the notebook and effectively solved dimensional difference and warpage problems. This not only improves the product quality but also saves the time and costs on mold trials. Meanwhile, it also helps find out that it is more effective to solve many molding problems in advance by taking product designing phase into consideration.
Since high-gloss parts demands extremely high surface quality, heat and cool process is implemented to ensure the surface quality and avoid shrinkage problem. Through analysis, we can predict the part thickness variations arisen with part thickness variations, large displacement, dimensional control, and severe dimensional difference. Uneven volumetric shrinkage will affect dimensional stability to a great extent; therefore, it is necessary to change the wall thickness in certain areas to improve the uneven volumetric shrinkage and effectively solve dimensional difference problem.
