Speed Up At Least 20% in Calculating Using BLM and eDesign Mesh

We’ve enhanced the calculation efficiency during different stages of Filling/Packing/Cooling by re-organizing software structure, which effectively reduces overall time needed for analysis.

True 3D Barrel Compression Simulation in Injection and Packing Stages

The dynamic compression behavior of materials is simulated in barrel and nozzle stages to elevate the injection pressure accuracy. It can couple with machine response that can predict VP-switch timing more precisely.

Augmented Warpage Simulation

The Insert Molding process considers the impact of first shot deformation on second shot warpage, which can provide a more accurate prediction. Moreover, version 2020 enables engineers to consider the cooling and warpage effects induced by the timing between mold open to ejection.

• Insert Molding Optimization



• Consider Delay Ejection in Simulation

Enhanced Advanced Cooling Simulation

Customized Heat Transfer Coefficient is added as a new function. It considers the heat resistance in the mold at different stages and among different components.

Groundbreaking Simulation Analysis for Special Pattern “Ear flow” in Injection Molding

Considers critical effect of extensional viscosity to improve Flow analysis in injection molding and provide the index for evaluating and predicting the special pattern, “Ear flow.”

Friendly and Comprehensive Simulation Platform ─ Studio

More comprehensive Studio capabilities:

• Insert Molding analysis
• RTM analysis
• Stress analysis and optimization analysis of DOE
• Powerful flatness roundness measuring tool (for part deformation)

Studio DOE Demo (Click here to watch more Studio demo videos)

New Mesh Tools Create Great Convenience and User Experience

• New tools that simplify mesh face-fixing workflow
• Geometry check and defect browser can spot defects faster
• The modeling wizards have been upgraded, including gate, runner and cooling channel

Integrate Moldex3D Simulation with NX and Creo Interfaces to Increase Work Efficiency

The new integrated service helps to combine Moldex3D simulation with CAD platforms (NX/Creo). The data can be analyzed simultaneously in CAD platforms and generate reports, which greatly improves work efficiency.

Most Advanced Simulation for Fiber-Filled Flow

With the most advanced coupling calculation of fiber and flow analysis, the system can predict how fiber length and concentration impact the flowing behavior automatically.

Improved RTM Advanced Features

The prediction accuracy can be increased by referring to 2D woven fiber mat in continuous fiber composite products.

Upgraded Foaming Advanced Features

• Enhanced the prediction accuracy of Foaming Process for injection pressure and clamping force by considering the impact of gas solubility and temperature.
• Added retraction process simulation for Chemical Foaming Molding that goes with the market demand of new manufacturing processes.

iSLM ─ A New Way to Store and Manage Your Simulation Data

iSLM is a Cloud-based platform, a new way to store and manage your simulation data. Users can access iSLM via browsers to view information, such as mold design documentation, material data tables, and Moldex3D simulation projects.  These data can all be managed online to achieve a streamlined workflow.

In addition to the streamlined workflow, iSLM is also equipped with tools to collect on-site mold trial results, which can be uploaded to iSLM instantly. Moreover, users can compare results from on-site mold trials to the ones from Moldex3D simulation.  It allows users to gather data quickly and further demonstrate the digital-physical integration!

Manage Your Knowledge Systematically (Solution Management)

Through iSLM, you can manage your knowledge systematically and solve problems like incomplete backups, hardware resources consumption and complex email exchange.

• Information can be accessed by multiple teams while the data is protected by permission settings
• Moldex3D projects can be stored systematically, keeping the workflow open and transparent
• Compare on-site mold trial and CAE simulation results simultaneously, showing digital and physical integration
• Your online document housekeeper that stores paperwork and DFM records

Digitalize the trial process: Results of on-site trials can be recorded online (Mold Tryout Management)

Say goodbye to lengthy paperwork process and unreadable notes.  All on-site mold trial data can be recorded on a digital platform to create an efficient working environment.

• Record on-site mold trial data online
• Acquire CAE parameter hints by using Solution Management to map trial data with CAE simulation
• Able to build customized templates to generate mold trial reports that meet business-standard specifications

Gain Product Development Insights from Your Own Database (Knowledge Management)

The Knowledge Management of iSLM can help industries quickly screen and compare different analyzed results via filters and user-defined categories to gain insights from their own database.

• Three filters are used to make information screening more efficient
• Advanced searching functions which help you locate projects faster
• Compare multiple project information simultaneously to acquire product development and design inspiration
• Make more comprehensive decisions by comparing mold trial data and CAE analysis
