- Date：Sep 26, 2024 - Sep 27, 2024
- Location： Gandhinagar, Bangalore
 |
 |
 |
Composite Manufacturing Process Simulation
Join us for Moldex3D’s two-day hands-on workshop on September 26-27, 2024 in Gandhinagar, Bangalore! Discover practical solutions to key design and manufacturing challenges and gain valuable insights. See the agenda below for more details.
Learn How to address Design and Manufacturing Challenges
- How to Perform Physical Material Testing? – Resin Characterization, Curing Kinetics, Reactive Viscosity
- How to Achieve Best Curing Behavior? – Optimal Mold Temp. Resin Thermal Properties, Heat Transfer
- How to Achieve Good Quality? – Void, Air-Trap, Resin Lack
- How to Predict Warpage? – Warpage / Deflection, Affects Product Quality
- How to Achieve Structural Strength & Stiffness? – Flow Behavior Affects
- Final Fibre Orientation hence Affecting the Structural Strength / Stiffness
- How to Predict Residual Stress? – Internal Stress / Residual, Stress Generated Influences, Product Quality
- How to Study Resin Rheology & Kinetics? – Filling Temperature, Flow Behavior, Curing Kinetics
- How to Achieve Flow Quality Improvement? – Dry Spots, Resin Lack, Micro Voids, Flash
- How to Detect Potential Flash Issue? – Predict Potential molding defects,such as bleeding or flashing
- How to Perform Structural Strength Analysis? – Structural Strength
- Evaluation with Manufacturing Quality Influence
- How to Achieve Fatigue life / Durability? – Optimal Resin Content, Lowest Void Content
- How to Perform Process Optimisation ? – Best Manufacturing
- Process for a Specified Composite Micro-Structure and Final Product
Join to learn more – Virtual Composite Manufacturing and Material Characterisation
Agenda
| Time | Topic | Delivered By |
| DAY 1 | ||
| 9:30 – 10:00 | Registration | |
| 10:00 – 11:00 | Mechanics of Composites | Dr. T Jagadish |
| 11:00 – 11:30 | Tea Break | |
| 11:30 – 12:15 | Composite Manufacturing Process and Parameters and Computational Modelling | Dr. T Jagadish – DHIO |
| 12:15 – 13:00 | Introduction to Composite Modelling using Moldex3D | Mr. Marirajan – Moldex3D Team |
| 13:00 – 14:00 | Lunch Break | |
| 14:00 – 14:30 | Introduction to RTM Molding Process, Process Parameter Considerations, Yield and Quality Issues | Mr. Santhosh N L – DHIO |
| 14:30 – 15:30 | Hands on Case Study 01 – RTM Molding Simulations – (Low Pressure RTM) | Mr. Marirajan – Moldex3D Team |
| 15:30 – 16:00 | Tea Break | |
| 16:00 – 17:30 | Hands on Case Study 02 – RTM Molding Simulations – (High Pressure RTM) | Mr. Marirajan – Moldex3D Team |
| 17:30 – 18:00 | Discussion and Closure | |
| DAY 2 | ||
| 10:00 – 11:30 | Hands on Case Study 03 – Compression RTM Molding Process | Mr. Marirajan – Moldex3D Team |
| 11:30 – 12:00 | Tea Break | |
| 12:00 – 13:00 | Hands on Case Study 04 : Material Characterisation / Homoginisation Analysis – Multiscale.sim | Mr. Rahul, Application Engineer – DHIO |
| 13:00 – 14:00 | Lunch Break | |
| 14:00 – 15:30 | Hands on Case Study 05 – Compression Molding Process Simulation | Mr. Marirajan – Moldex3D Team |
| 15:30 – 16:00 | Tea Break | |
| 16:00 – 17:30 | Hands on Case Study 06 -Moldex3D – Stress and FEA Interface Simulation for Composites | Mr. Marirajan – Moldex3D Team |
| 17:30 – 18:00 | Discussion and Closure | |
Venue
Hotel IV-Sanctum, Gandhinagar, Bangalore
Registration details
INR 3,000.00+Tax (18%)
Register here: https://lnkd.in/gDvtr49V
Contact
Mrs, Shivangi US
E: shivangi@dhioresearch.com
T: +91 959137 7611. 9591994642
Ms. Poshitha
E: poshitha@dhioresearch.com
T: +91 7019248044
