Webinar: Conformal Cooling and Simulation

  • Date:Nov 09, 2016
  • Location: 10:00 AM CET/ 2:30 PM IST

11.9
Conformal cooling of injection molds is a game changer in the molding industry. Typical cycle reductions of 20 to 40 percent can be realized, lower reject rates are accomplished because of uniform cooling and stronger parts are achieved through lower molded-in stress. However, compared to other conventional cooling techniques, conformal cooling channel design is an intricate and complicated matter, and mold inserts used in conformal cooling system are more costly. Therefore, designing and verifying an effective conformal cooling system have been critical for its users.

In this webinar, we will introduce how CAE simulation software can successfully assist in evaluating the effectiveness of cooling layout designs and verify potential design problems at early stage. For example, physical properties such as pressure, temperature, and flow velocity can be presented in three dimensional inside cooling channels. Users can detect potential design problems based on analysis results. In addition, through cooling time prediction, users will perceive the effect of cycle time on a cooling system.

View Recording
